The Nikon A1R HD25 confocal microscope system boasts an industry leading 25mm field of view which allows researchers to capture more data in a single shot. Six laser lines and a variety of detection options allow for a wide range of experiments. The 8kHz resonant scanner facilitates live cell imaging with reduced photobleaching and phototoxicity. Software benefits include 2D/3D deconvolution, denoise.AI, and JOBS for customized acquisition routines.
- Point scanning confocal with 25mm field of view on an inverted Nikon Ti2-E body
- Galvano and resonant scanners
- Tokai Hit stage top incubator for CO2 and temperature control (Model STXG)
- multi-color, z-stacks, time-lapse imaging, multipoint capture, tiling
- Nikon Perfect Focus System
- FRAP, FLIP, FRET, photoactivation, colocalization, reflection imaging
- Software options include: denoise.AI, 2D/3D deconvolution, JOBS
Objectives
Laser lines (nm)
Detectors
A1-DUG-2 GaAsP Multi Detector Unit
- two Multi-Alkali PMTs
- two GaAsP PMTs
A1R-HD DUV-B 2 Channel GaAsP Spectral Detector
Transmitted Light Detector
- CO2 incubator at 37°C for live-cell samples until their turn to be imaged
- No ibidi polymer slides if using immersion objectives.
Primary contact
Laura Fox-Goharioon lfoxgoh@emory.edu
